• Swing Over Bed Ways: 14-1/8”
• Swing over Cross Slide: 8-1/4”
• Distance Between Centers: 30”
• Spindle Bore: 1-3/8”
• Spindle Nose: A1-5
• Spindle Speeds (6): 83 to 1030 RPM
• Cross Slide Travel: 8”
• Compound Rest Travel: 5”
• Thread Range:
  • Inch: 2 to 56 TPI
  • Metric: 0.5 to 9 mm
• Feed Range
  • Longitudinal: 0.0020 to 0.1417 IPR
  • Cross: ½ Longitudinal Rate
• Tailstock Center Taper: #3 MT
• Tailstock Quill Travel: 5-3/4”

Equipment

• 3 Jaw Universal Chuck
• 0-1/2” Capacity Drill Chuck
• Motor and Controls: 5 HP 3/60/220V AC
• Floor Space: 70” L-R x 36” F-B x 48” High
• Weight: 2450 Lbs. (Approx.)

Stock #7805P
Serial #BSE80475H
