• Working Surface: 6” x 12”
• Longitudinal Table Travel: 13”
• Cross Feed Travel: 7”
• Vertical Working Height, Under 7” Wheel – 11-1/4” to Table Surface
• Grinding Wheel Size: 7” x 1-1/4” Bore x ½” Thickness
• Spindle Speed: 3,000 RPM
• Table Feed Mechanism, Manual: Rack & Pinion
• Cross Feed Handwheel Graduation: 0.001”
• Elevation Handwheel Graduation: 0.0005”

Equipment

• O.S. Walker Ceramax 6” x 12” Permanent Magnetic Chuck
• Built-In Dust Collector
• Bijur Lubrication
• Work Light
• Motor and Controls: 1 HP 3/60/208-220/440 Volt AC
• Floor Space: 44” L-R x 39” F-B x 65” High
• Weight: 770 Lbs. (Approx.)

Stock #7774P
Serial #27027
