• Table Working Surface: 9” x 42”
• Longitudinal Table Travel: 30”
• Cross Travel of Table: 12”
• Vertical Travel of Knee: 16”
• Overarm (Ram) Travel: 12”
• Spindle Taper: R-8
• Spindle Speeds: 80 to 2720 RPM
• Quill Feeds (3): .0015, .003, .006 IPR
• Overarm / Head Swivel on Turret: 360 Degrees
• Head Tilt, Front to Back, Plus/Minus: 45 Degrees
• Head Tilt, Left to Right, Plus/Minus: 90 Degrees

Equipment

• Kurt 6” Milling Vise
• Ribbon Chrome Ways
• Side Mount Collet Rack with R-8 Collets
• Drill Chucks
• Anilam Mini-Wizard 2-Axis Digital Readout System
• One-Shot Lubrication
• Rotary Table
• Horizontal/Vertical Indexing Head with Plates
• Large Quantity of Smaller Accessories & Tools
• Motor and Controls: ¾ HP 1/60/220 Volt Single Phase
• Floor Space: 60” L-R x 60” F-B x 84” High
• Weight: 2,000 Lbs. (Approx.)

NOTE: Machine Purchased New by Single Owner/Operator Home Hobby Shop – Excellent Condition

Stock #7770P
Serial #BR12-114052
