• Swing Over Bedways: 17-1/8”
• Swing in Partial Gap: 19-1/4” (6-1/4” Back from Faceplate)
• Swing Over Cross Slide: 9-3/4”
• Compound Travel on Carriage: 9-5/8”
• Width of Bed: 13-3/4”
• Distance Between Centers: 47”
• Spindle Bore: 2-3/64”
• Spindle Nose: A1-6
• Taper in Spindle Bore: #6 MT
• Spindle Speeds (12): 32 to 1800 RPM
• Threading- Inch/Metric: 4 to 80 TPI/ 0.5 to 7 mm
• Longitudinal Feed (40): 0.0035 to 0.050 IPR
• Cross Feeds: 0.0018 to 0.025 IPR
• Tailstock Taper: #4 MT
• Tailstock Spindle Travel: 6”

Equipment

• 10” 3-Jaw Universal Chuck with 2-Piece Reversible Top Jaws
• Quick Change Toolpost
• Threading Dial
• Coolant Pump
• Foot Actuated Spindle Brake
• Motor and Controls: 5 HP 3/60/220-440 Volt AC
• Floor Space: 101” L-R x 35” F-B
• Weight: 4800 Lbs. (Approx.)

Stock #7757P
Serial #9-8007-50
